CAE Modeler Software

CAE Modeler Software

CAE Modeler is a generalized materials pre-processor software that converts material properties into material model inputs for supported CAE applications. The software operates on material properties stored in databases on the Matereality Cloud. Material parameter conversion capability includes simple elastic, elastic-plastic, hyperelastic, rate dependent, fatigue and viscoelastic material models for FEA, plus injection-molding simulation parameters.

Because each material model has specific data requirements, the software first assembles materials that have the required properties from the material database. CAE Modeler then performs material parameter conversion and writes files readable by the supported CAE software. Where needed, a graphical user interface allows you to edit and tune the material parameters for higher fidelity.

Note: Matereality's CAE Modelers are integrated within partner software programs including Abaqus/CAE, ANSYS Workbench, Moldex3D and SIMPOE. Some of these require a plug-in to operate.

Pricing: CAE Modeler Software is included with your Matereality Database.


CAE Partners: Click icons for tutorial videos

Simulia
Software to convert material data into Abaqus material model files, including elastic, plasticity, hyperelastic, rate-dependent, and viscoelastic models; download a plug-in to run Matereality within Abaqus/CAE


Autodesk Simulation Mechanical
Software to convert material data into Algor-format material model files


Ansys
Software to convert material data into ANSYS material model files, including elastic, plasticity, hyperelastic, rate-dependent, and viscoelastic models; download a plug-in to run Matereality within Workbench


LS-DYNA
Software to convert rate-dependent tensile data and create MAT24 material cards


Moldex
Software to send viscosity, PVT, and shrinkage data to Moldex3D; Matereality runs within Moldex3D


Autodesk Simulation Moldflow
Software to create Moldflow *.udb files from viscosity, PVT, and shrinkage data


NX Nastran
Software to convert material data into NASTRAN material model files, including elastic, plasticity, and hyperelastic models


ESI PAM-CRASH
Software to convert rate-dependent tensile data and create MAT103 material cards


Simpoe
Send viscosity, PVT and shrinkage data to SIMPOE.


Solidworks
Software to locate data for SolidWorks studies and create material models for direct input into SolidWorks; Matereality runs within SolidWorks 2014

Video by GoEngineer
